Description

Garmat® USAs Zephyr booth is our most economically priced Downdraft Spray Booth. The Zephyr gives you the reliability and performance you have been looking for, in an economical package that fits most budgets.

Featuring the premium air flow and optimal lighting you expect in a Garmat Paint Booth. This model features dual inlet reverse incline fans on both supply and exhaust, horizontal oriented interior accessible lighting and a single row pit. The intake and exhaust filter layouts are designed for even velocity throughout the working area of the booth providing consistent air flow required for a quality paint job. Using positive pressure within the paint booth prevents contamination from entering the booth. Cleaner air translates into cleaner higher quality paint jobs.

Garmat spray booths offer the most effective airflow in the market


Engineered with production enhancing features that help increase your throughput while decreasing your operating costs. High efficiency throughout, whether it be incorporated in the actual operation of the spray booth or simplifying maintenance to ensure continued optimal performance.

The Highlights


24ft Zephyr Downdraft Spray Booth

Interior:

23′ 11-5/8″ L x 13 1- 1/2″W x 8′ 10-1/2″ H

Exterior:

24 4-3/8” L x 13 6 -5/8” W x 10’10”H

Mechanical:

4’W x 9’ 11” x 10’ 10”

Light Fixtures:

  • 13 Light fixtures / 52 Light tubes DIBO
  • 14 Light fixtures / 53 Light tubes DT
  • Horizontal orientation for optimal illumination. All interior accessible for ease of maintenance.

Pit Configuration:

Single Row equipped with light weight heavy duty grates

Operations and Controls:

  • Dual Inlet Reverse Incline Fan featuring Airfoil Blades on Supply and Exhaust
  • (2) 7.5 HP High Efficiency Motors
  • 84K BTU Direct fired heater with fast temperature rise, features Aluminum and Stainless Steel Burner construction
  • PLC Listed Industrial Control Panel
  • Recycle on Bake
  • Upgrades to 99275 or 99273 Mechanical available

27ft Zephyr Downdraft Spray Booth

Interior:

26′ 9-/1/4″ L x 13 1- 1/2″ W x 8′ 10-1/2″ H

Exterior:

27 2-1/4” L x 13 6 -5/8” W x 10’10” H

Mechanical:

4’W x 9’ 11” x 10’ 10”

Light Fixtures:

  • 13 Light fixtures / 52 Light tubes DIBO
  • 14 Light fixtures / 53 Light tubes DT
  •  Horizontal orientation for optimal illumination. All interior accessible for ease of maintenance.

Pit Configuration:

Single Row equipped with light weight heavy duty grates

Operations and Controls:

  • Comes standard with 99270E Mechanical
  • Dual Inlet Reverse Incline Fan featuring Airfoil Blades on Supply and Exhaust
  • Accele-Cure® Air Accelerate Drying System
  • (2) 7.5 HP High Efficiency Motors
  • 84K BTU Direct fired heater with fast temperature rise, features Aluminum and Stainless Steel Burner construction
  • PLC Listed Industrial Control Panel
  • Recycle on Bake
  • Upgrades to 99275 or 99273 Mechanical available
